Lesson 5: Water Conservation App - Interactive

📚 Previous Lesson

Coming from Lesson 4: Mad Libs Game? Great! Now you’ll make your Water Conservation App interactive by adding JavaScript functionality.

🎯 Learning Objectives

Update your Week 4 Water Conservation App HTML wireframe to be interactive
Add JavaScript event handling to existing Bootstrap components
Practice DOM manipulation with helper functions

🚀 Project Overview

Update your existing Week 4 Water Conservation App to make it interactive. You’ll add JavaScript functionality to the HTML wireframe you already created.

Reference: If you need to review how the Water Conservation App HTML was built, see Week 4: Bootstrap Layouts and Grid System.

🛠️ Setup

Step 1: Open Your Project in VSCode

Open VSCode
Go to File → Open Folder
Navigate to your water-conservation-app project folder
Click Select Folder

Step 2: Download Helper Functions

Download Helper Functions - Pre-built functions for common tasks
Save the file as helpers.js in your project folder
Important: Keep the filename exactly as helpers.js

Step 3: Add Helper Functions to HTML

Add this line to your HTML file, just before the closing </body> tag:

<script src="helpers.js"></script>

Step 4: Create Your JavaScript File

Create a script.js file in your project and include it under helpers.js in your html file.

In VSCode, right-click in the file explorer
Select New File
Name it script.js
Add this line to your HTML file, after the helpers.js script:
```
<script src="script.js"></script>
```

Step 5: Learn About Helper Functions

For detailed information about available helper functions, see Helper Functions Guide.

Repeat for each html file

You should create a new JavaScript file for each of the html files you have.

Include the helpers.js and your new script file in each page.

For example, for water-bottle-screen.html, you could have a script called water-bottle-screen.js. For shower-screen.html, you could have a script called shower-screen.js.

🌊 Interactive Features to Add

Based on the Week 4 Water Conservation App screenshots, add these interactive features:

Original App on Code.org

Review the original app on code.org.

Link to Water Conservation Tips App on code.org

Screen 1 (Home/Language)

Language Toggle: Switch between English and Spanish
Navigation: Button to proceed to bottle selection screen
Multilingual Content: Title and body text in both languages

Screen 2 (Bottle Selection)

Bottle Choice: Click good vs. bad bottle with visual feedback
Feedback System: Success/error messages with sound effects
Cross Overlay: Visual indicator for wrong bottle choice
- plastic-bottle-no.png - Plastic bottle with no indicator
- no.gif - No/negative response animation
Bonus Challenge: Faucet Interaction: Fill bottle after correct selection (This is quite hard to do with bootstrap. You may skip the bottle movement and filling.)

Screen 3 (Shower Timer)

Image Toggle: Timer click swaps shower before/after images
- yellow-rubber-duck.jpg - Shower before image
- times-up.jpg - Shower after image
Visual Feedback: Artwork changes based on user interaction
Navigation: Return to home screen

Implementation Tips

Start with Bootstrap: Use your existing Week 4 knowledge and Bootstrap components
Focus on Screens: Work on one screen at a time (Screen 1 → Screen 2 → Screen 3) Note: Each “screen” is it’s own page. Different from code.org, the screens cannot share state. All variables will be reset after each navigation.
State Management: Track language, bottle selection, and shower state within the page.
Event Handling: Add click events for buttons, images, and interactions
Visual Feedback: Use overlays, image swaps, and Bootstrap classes
Test Incrementally: Check each feature as you build it
Refer to Code.org: Use the lessons for JavaScript implementation details

🔗 Additional Resources

Basic JavaScript Snippets - Complete JS reference for VSCode projects
Event-Driven Programming in App Lab - Complete module with lessons and videos
JavaScript Reference - Quick JS syntax and concepts reference
Helper Functions - Pre-built functions for common tasks
Bootstrap Components Review - W3Schools Bootstrap 5 Tutorial
Code.org App Lab Tutorial - Learn how to use App Lab effectively

🖼️ Assets

Week 5 Images

times-up.jpg - Timer completion image
yellow-rubber-duck.jpg - Yellow rubber duck image
plastic-bottle-no.png - Plastic bottle with no/negative indicator
no.gif - No/negative response animation

📚 Next Lesson

Ready to build the Mad Libs game? Continue to Lesson 6: Mad Libs Game - Interactive to make your HTML wireframe interactive!

🏆 Bonus Challenge

Multiple Bottle Saves

On Screen 2, enhance the bottle selection to allow users to click the good bottle multiple times and track their conservation impact:

Bottle Counter: Add a counter that increments each time the good bottle is clicked
Multiple Saves: Allow users to “save” multiple bottles by clicking repeatedly
Visual Feedback: Show the current count of bottles saved
Conservation Impact: Display environmental impact based on bottles saved

Implementation Ideas

Track bottle count in app state
Update counter display after each good bottle click
Consider adding animation or visual feedback for multiple saves
Show cumulative environmental impact (e.g., “You’ve saved X plastic bottles!”)

This challenge adds replayability and helps users understand the cumulative impact of their conservation choices.
